Products

20–40 Ton Roll-Off

• Your choice of Tandem or Tri-Axle

• Your choice of Outside Rollers, Inside Rollers, Outside Skid, or Inside Skid

• Inside & Outside Controls

• Tilting frame with 10" and 12" boxed structural channel

• C.D.E. exclusive one sheave, one drive pull on cylinder

• Single stroke twin pull on cylinder available for 25 and 30 ton hoists

• Handles 14 to 50 cubic yard containers

• Full fenders and lights

• Cable diameter: 7/8" — lengths available: 19', 21'7", 24'8" with eye or hook ends

• Hydraulic gear-type pump



10 Ton Roll-Off

• 15' Main Rails

• 10 Ton Capacity

• Forward load shift for better weight distribution

• Cable cylinder: 5" bore, 10 ton capacity

• 5/8" cable with open hook and safety latch

• Two lift (tilt) cylinders mounted inboard, 5" bore

• Hydraulic oil tank with filler breather and shut-off gate valve

• Return line oil filter and sight gauge

• Hydraulic pump & PTO

• 2-section hydraulic valve, chassis side-mounted

• In-cab valve control levers

• Manual outside controls

• Tool box with checker plate lid

• Checker plate fenders over rear axle

• Mud flaps front and rear of fenders

• All lights LED, pop-in style

• 2 spotlights on a separate switch

• Unit requires a C.A. of 121"

• Entire unit primed and painted one color (enamel)

​

4 Ton Roll-Off

• 15'3" Main Rails

• 4 Ton Capacity

• Forward load shift for better weight distribution

• Cable cylinder: 4" bore, 4 ton capacity

• 5/8" cable with open hook and safety latch

• Two lift (tilt) cylinders mounted inboard, 4" bore

• Hydraulic oil tank with filler breather and shut-off gate valve

• Return line oil filter and sight gauge

• 2-section hydraulic valve, chassis side-mounted

• Cable controls

• Tool box with checker plate lid

• Clutch Pak pump

• Checker plate fenders over rear axle

• Mud flaps front and rear of all fenders

• All lights LED, pop-in style

• 2 spotlights on a separate switch

• Chassis requires a C.A. of 108"

• Entire unit primed and painted one color (enamel)

​

Extendable / Retractable Tail System

• 26' Rail Length

• 60,000 lb Capacity

• Frame: H.S.S. tube construction

• Hydraulic extension

• Tie-down hooks welded onto bottom of tail

• Rail type: Top skid

• Two standard front container stops

• 30 ton cable cylinder

• Pull-on cylinder cover

• 11" diameter sheave and bracket

• Push bar on pulley

• 7/8" diameter cable with safety hook

• Two 7" lift (tilt) cylinders

• Manual safety prop on hoist

• Standard rear stops

• Hydraulic rear stabilizer

• Hydraulic oil tank with filler breather and shut-off gate valve

• Hydraulic filtered return line and sight gauge

• Hydraulic valve, chassis mounted

• Hydraulic pump and PTO, direct coupled

• 2" red dash-mounted light for PTO

• In-cab air control levers (console mounted)

• Manual outside levers

• Two tool boxes with checker plate lids

• Tool box lids split in two sections

• Curved checker plate fenders over tandem axle

• Lighting to federal code (all pop-in LED)

• 2 spotlights on toggle switch

• Installed on suitably prepared chassis with 60" spread and 200" clear C.A.

• Entire unit primed and painted one color enamel
